Reference exhibited sample at International Technical Exhibition on Image Technology and Equipment 2013
High Power LED Projector/HLP-１Catalog Download (PDF)
Specifications are subject to change without prior notice.
Projector light embedded high power LED light source. With our unique optical design, achieved higher efficiency than ordinary products.
| Focal length of collimate lens | f=200mm |
|---|---|
| Beam angle | 1.5 degree（at half illuminance） |
| Projection distance | 30m |
| Bright area | Φ680mm |
| intensity | 500Lx（ave.） |
Various shapes of bright area can be materialize by the shape of aperture inside.
 Oval |
 Square |
Appearance View
Specification
| Dimension | Φ156ｍｍ x 275ｍｍ |
|---|---|
| Weight | 3.7g |
| Power Consumption | approx. 50W |
| Projection Lens | Acrylic Fresnel Lens |
| Illuminance intensity | 500Lx（ave.） |
